ID: 2634 Open
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP
SLIDING TABLE SAW - 7.5 HP

SLIDING TABLE SAW - 7.5 HP

AMXmachine1

Contact Seller
Description
PARTE: 2MK-BMP.3200.IR - SLIDING TABLE SAW - 7.5 HP


Is a powerful sliding panel saw from Maksiwa, equipped with a 7.5HP main motor and ¾ HP Scoring motor (3 phase). The 126” sliding table is constructed of anodized aluminum and runs on precision linear guide rails that gives you an ultra-smooth movement allowing you to move the table effortlessly. Designed with a European style 51″ rip fence, it has a digital readout with a micro adjustment for fine-tuning; simply lock it in place and adjust fence incrementally. The rip fence consists of a heavy-duty casting riding on a micro-polished solid steel bar.

Our heavy-duty anodized aluminum crosscut fence features two solid flip-stops, telescoping function (max 120″), 45° miter and is ergonomically designed to make it easier to read the tape. The control panel is conveniently located on an eye-level position with easy access to the main operation buttons. It comes standard with two overhead guards 90° and 45° featuring a quick-change and swing-away function, easily switch from one to the other in a matter of seconds and move the guard out of the way easily if necessary. It also includes a push handle, hold-down clamp and wedge clamp.

Technical Information
Main Motor7.5 HP/ 4000 RPM 5.5 Kw
Max Blade Diameter14" | 355mm
Main Blade Arbor1 3/16" | 30mm
Main Blade Max cutting Height at 90°3 1/2" | 90 mm
Main Blade Cutting Height at 45°2 7/16" | 63mm
Scoring Motor3/4 HP / 8000 RPM .74Kw
Scoring Blade4 3/4" | 120mm
Scoring Blade Arbor25/32" | 20mm
Scoring Blade TypeConical
Max Ripping Capacity51" | 1300mm
Crosscut Capacity126" | 3200 mm
Crosscut Fence Capacity Closed/Open78" / 120" | 1981mm / 3048 mm
Machine Working Dimensions (LxWxH)132" x 137" x 75" | 3352 x 3479 x 1905 mm
Cast Iron Table Dimension (LxWxH)35" x 21" x 34" | 896 X 548 X 864 mm
Sliding Table Dimension (LxW)126" x 14 " | 3200 x 358 mm
Dust Collection Port (2)4" | 100mm
Minimum Dust Collection Requirements1000 CFM | 28m/min
Electrical Specs3 Phase 220V 30 Amps 60 Hz
Main Body Crate Dimensions (LxWxH)83" x 45" x 45" | 2108x 1143 x 1143 mm
Main Body Crate Weight Net/Gross1470 LBS | 667 KGS
Sliding Table Crate Dimensions (LxWxH)133" x 18" x 15" | 3378 x 457 x 381 mm
Sliding Table Crate Weight Net/Gross274 LBS | 124 KGS
Payments & Returns
Payment Methods
N/A
Post Message
Sign in to ask the seller a question.
COMBINATION FACE FRAME AND DOOR CLAMPING EASEL
AMXmachine1
COMBINATION FACE FRAME AND DOOR CLAMPING EASEL
PARTE: 2RI-R475EA - COMBINATION FACE FRAME AND DOOR CLAMPING EASELDescription:Frame assembly system for doweled, mortise and tenon, or screwed together frames and cabinet doors. Screwed together face frame construction provides for the most efficient and economical methods for joining frames. Flush and tight joint construction is provided for all types of wood. Elimination of dowel boring and insertion, clamping time and joint misalignment provide up 50% time reduction in frame production. The ...
TRIPLE SPINDLE HORIZONTAL BORER
AMXmachine1
TRIPLE SPINDLE HORIZONTAL BORER
PARTE: 2RI-R131 - TRIPLE SPINDLE HORIZONTAL BORERDescription:Designed for a dedicated and accurate boring center with single, double or triple spindle boring capability. Stile and rail boring set-up features help eliminate costly mistakes, rejected parts and increase production efficiency. The workpiece is held firmly against the table by a pneumatic clamp, and there is full adjustability of the index stops, bed height, and depth of cut.Standard Features:Triple Spindle Gear Driven Drill Head1...
DOBLADORA DE METAL 12'6'' x 22
AMXmachine1
DOBLADORA DE METAL 12'6'' x 22
DOBLADORA DE METAL 12'6'' x 22              PARTE: 2GM-SBB1222Machine Tools 12-foot Siding Brakes are a portable, foldable solution designed for precision sheet metal bending in roofing and HVAC applications. Built with a heavy welded snap steel stand for stability, this tool ensures durability and reliability on any job site. Featuring a cut-off shear for clean, accurate cuts, it’s the ideal companion for roofers and HVAC professionals seeking efficiency and precision. ISO 9001 cer...
Horizontal Bore & Dowel Insertion Machine
AMXmachine1
Horizontal Bore & Dowel Insertion Machine
PARTE: 2PI-H49 - Horizontal Bore & Dowel Insertion MachineIs a horizontal point to point bore and dowel insertion machining center.It is designed to CNC position the spindle, bore a hole, then CNC position the inserter, inject glue or water (for pre-glued dowels), and fire the dowel into the hole.Elimination of complicated machine setupQuick, accurate assemblyGain production times on CNC routers and point to points by shifting boring and doweling
