PART:
4BA-DPM-ED-2141-E – VERTICAL PANEL SAW - CAP. 2100 MM X 4100 MM X 60 MM - BALA
New with warrantyDemo
model with about 30 hours on it
Specifications
-
Comes with digital readouts on the vertical and horizontal axis, readout in
decimal inches or mm
-
Processing sheets both horizontally and vertically
-
Cutting height is 2100mm
-
Cutting length is 4100mm (161") Actual overall length of machine is 16’.4”
-
Weight 2400 lbs
-
Thickness of cut is 0-60mm
...
PART:
1AM-3010-E – ROLLER STAND - INFEED - OUTFEED - 120 CM (47”) LENGTH
SIDE
ROLLER TABLES Use
with saws, planers, edgebanders, jointers, etc.120
cm (47”) length x 39 cm (15.35”) widthVariable
height 83 - 87 cm (32.5 - 34.25”)Support
large and heavy wood pieces and wood panelsAdjustable
heigh to pair with your current machines
7
galvanized steel ball bearing rollersOptional:
- Custom lengths
PARTE: 4VF-VC6 – SOLDADORA DE SIERRA CINTASReliable, inexpensive and very easy to use.Manual welding and annealing.Shear included.Steel Band Width [min-max]: 20 – 60 mmBand Thickness [min-max]: 0,5 – 1,1 mmPower Absorbed: 4,5 kWNet – Gross Weight: 51 – 72 kgMachine Dimensions [D x W x H]: 49 x 52 x 32 cmPacking Dimensions [D x W x H]: 62 x 82 x 50 cm
PARTE:
1SL-DC-CH18F - TALADRO DE COLUMNA - MOTOR 1.2 HP - 110V, 1 FASENUEVO CON GARANTIAMOTOR: 1.2 HP, 110V, 60 Hz, 1 FASE12 VELOCIDADES: 340 - 2860 RPMCHUCK: 5 A 20 MM (3/4")DISTANCIA DEL CHUCK A COLUMNA: 175 MMCARRERA CHUCK: 85 MMDISTANCIA DEL CHUCK A LA MESA: 565 MMDISTANCIA DEL CHUCK A LA BASE: 1050 MMDIMENSIONES DE LA MESA: 285 X 285 MMDIMENSIONES TOTALES: 1140 MM X 500 MM X 300 MMPESO: 80 KGSEMPAQUE: 1 CAJA* INCLUYE PRENSA DE 4"
