Description
PARTE: 2MK-CP/2.C - DUST COLLECTOR - 2 HP
Is ideal for collecting light powder from small and medium machines such as saws and sanders. The air flow of this collector is 1,165 ft³/min, resulting in a clean and pleasant environment for your work. The large bag has a capacity of 5.4 sq. feet.
| Technical Information | |
|---|---|
| Motor Specs | 1 Phase 220V 2HP 15 Amps 60Hzs |
| Air Flow capacity | 1490 CFM |
| Fan Diameter | 12" | 305mm |
| Bag Capacity | 5ft3 |
| Number of air intel | 2 |
| Inlet size | Main:5" |125mm - Spliter: 4" | 100mm |
| Filtration | 1 micron |
| Sound Rating | 89 dB |
| Weight | 95 Lbs | 43kg |
